2. FUNCTION EXPLANATION
B–65160E/02
146
Parameter PRM 5820 #0 or #1=”0” Counterclockwise (CCW)
Parameter PRM 5820 #0 or #1=”1” Clockwise (CW)
(8) The gear ratio of the spindle to the position coder can be set only to
one to one.
Identical gear ratios must be set for the 1st and 2nd spindles.
(Parameters 5610 and 5660)
(9) Sequence state in spindle synchronization control
#7 #6 #5 #4 #3 #2 #1 #0
1508 SPSYC3 SPSYC2 SPSYC1 SPSYC0
SP
SYC3
SP
SYC2
SP
SYC1
SP
SYC0
Internal processing state
0 0 0 0
The spindles are not in spindle
synchronization control mode.
(SPSYC = 1 is waited.)
0 0 0 1
Waits for the signal that indicates
that synchronization speed has
been reached to be generated.
(Synchronization control of spindle
speed is in progress.)
0 0 1 0
Waits for the signal that indicates
that synchronization speed has
been reached to be set.
0 0 1 1
Waits for the signal that indicates
that synchronization control of
spindle speed is completed and
the command for spindle phase
synchronization to be generated.
(Waits for SPPHS = 1.)
0 1 0 0 Phase synchronization, on/off
0 1 0 1
Waits for the signal that indicates
that synchronization speed has
been reached to be cleared.
(Synchronization control of spindle
phase is in progress.)
0 1 1 0
Waits for the signal that indicates
that synchronization speed has
been reached to be set.
0 1 1 1
Synchronization control of spindle
phase is in effect.
