Open CNC Basic Operation Package 2 Operators manual Page 113

Operators manual
B-63924EN/01 2.STANDARD OPERATION
- 93 -
2.3.5.3 Displaying the top/end of an MDI program
The top or end of the MDI program being edited can be displayed.
Procedure
1 If the [MDI Program] screen is currently not displayed, display
the [MDI Program] screen as described in Subsection 2.3.5,
"Editing an MDI Program".
2 Press the display/operation switching key
to display the
operation keys.
3 Press the operation key
to move the cursor to the top
of the MDI program.
4 Press the operation key
to move the cursor to the end
of the MDI program.
2.3.5.4 Sending an MDI program to the CNC
The MDI program being edited can be sent to the CNC.
Before executing an MDI program on the CNC after editing the
program on Basic Operation Package 2, be sure to send the program to
the CNC.
Procedure
1 If the [MDI Program] screen is currently not displayed, display
the [MDI Program] screen as described in Subsection 2.3.5,
"Editing an MDI Program".
2 Press the display/operation switching key
to display the
operation keys.
3 Press the operation key
to send the MDI program to
the CNC.
