Open CNC Basic Operation Package 2 Operators manual Page 45

Operators manual
B-63924EN/01 2.STANDARD OPERATION
- 25 -
Confirms the input of a numeric value
(writes a numeric value to the CNC).
Timer
Cancels the input of a numeric value.
Switches the type of display data.
(Geometry data for a lathe system, or tool
length data for a machining center system)
Switches the type of display data.
(Wear data for a lathe system, or tool
radius data for a machining center system)
Clears all tool offset data to zero.
Inputs a measured tool offset value.
(Inputs a numeric value directly.)
Displays a specified number.
Inputs tool offset data as an incremental
value.
Tool Offset
Inputs a tool offset data counter value.
(Sets a relative coordinate.)
Switches the type of display variable.
Custom Macro
Inputs a custom macro variable as an
incremental value.
