Open CNC Basic Operation Package 2 Operators manual Page 211

Operators manual
B-63924EN/01 2.STANDARD OPERATION
- 191 -
NOTE
Before the data table of the PMC data can be
displayed, table control data must be set.
For the method of setting table control data, see
Subsection 2.5.11.2, "Setting the table control data
of PMC data".
Procedure
1 If the [PMC Data] screen is currently not displayed, display the
[PMC Data] screen as described in Subsection 2.5.11, "Setting
PMC Data".
2 Press the display/operation switching key
to display the
operation keys.
3 When you press the operation key
on the group table
of a group number to be set, the screen display is switched to the
data table screen.
For the items displayed on the screen, see "Explanation".
4 On the screen of the BYTE type, WORD type, or DWORD type,
the cursor can be moved to a desired item by pressing the
[PageUp] or [PageDown] key on the keyboard ([↑PAGE] or
[↓PAGE] key on the MDI panel) or the [←], [→], [↑], or [↓]
(cursor) key.
5 On the screen of the BIT type, the cursor can be moved to a
desired item by the following operation:
a) By pressing the operation key
or , the
[PageUp] or [PageDown] key on the keyboard, or the
[
↑
PAGE] or [
↓
PAGE] key on the MDI panel, move to the
desired page.
b) By pressing the operation key
or , or the
[
↑
] or [
↓
] (cursor) key on the keyboard or MDI panel, move
to the desired item.
c) By pressing the operation key
or , or the
[
←
] or [
→
] key on the keyboard or MDI panel, select a
desired bit.
6 Press the operation key
on the data table screen to
return to the table control data screen.
