Open CNC Basic Operation Package 2 Operators manual Page 166

Operators manual
2.STANDARD OPERATION B-63924EN/01
- 146 -
2.5.1.2 Setting parameters
A parameter can be set.
NOTE
To set a parameter, set the following status:
• Setting
- Enable Parameter Write.
• Operation
- Emergency stop, or
- Stopped or paused in MDI mode
For the method of setting of settings, see
Subsection 2.4.1, "Setting of Settings" or
Subsection 2.5.1.3, "Enabling parameter write".
Procedure
1 If the [Parameter] screen is currently not displayed, display the
[Parameter] screen as described in Subsection 2.5.1, "Displaying
Parameters".
2 Press the display/operation switching key
to display the
operation keys.
3 Select an item to be set.
4 When setting a data item for which a numeric value is to be set,
enter a desired value through the keyboard or MDI panel.
Press the operation key
or the [Enter] key on the
keyboard, or click the [INPUT] button on the MDI panel to set
the input value with the CNC.
Press the operation key
or the [Esc] key on the
keyboard, or click the [CAN] button on the MDI panel to cancel
the input.
5 The value of a data item of bit type (for which the check box is
turned on or off) can be changed by pressing the operation key
or or by pressing the space key on the
keyboard.
