B-63924EN/01 2.STANDARD OPERATION
- 135 -
2.4.5 Setting Workpiece Origin Offset
A workpiece origin offset value can be set based on the position of the
workpiece origin viewed from the machine zero point.
This screen can be displayed by pressing the [SETTING] function key
and [WORK OFS] submenu key.
WARNING
Setting incorrect workpiece origin offset data may
result in unpredictable movement of the machine,
resulting in damage to the workpiece, the machine
itself, or injury to the operator or bystanders. Set
workpiece origin offset data that is appropriate for
the machining program.
NOTE
To set workpiece origin offset data, the
corresponding CNC option is required.
Moreover, set the following status:
• Protect key
- Released
For the release of the protect key, refer to the
relevant operator's manual of the machine tool
builder.
