Open CNC Basic Operation Package 2 Operators manual Page 208

Operators manual
2.STANDARD OPERATION B-63924EN/01
- 188 -
2.5.11.4 Initializing the table control data of PMC data
The table control data of the PMC path currently displayed can be
initialized on the table control data screen.
All of the contents of the set group tables are deleted.
Procedure
1 If the [PMC Data] screen is currently not displayed, display the
[PMC Data] screen as described in Subsection 2.5.11, "Setting
PMC Data".
2 Press the display/operation switching key
to display the
operation keys.
3 Press the operation key
to display the [PMC Data -
Init] screen.
4 Click the <OK> button. The table control data is
initialized.
After initialization, the total number of group tables is 1.
