6.SAFETY FUNCTIONS OPERATION B-63324EN-1/03

- 194 -

- Effective time for a forbidden area

Each limit becomes valid when reference position return has been

performed manually or by G28 after power-up.

After the power is turned on, if the reference position is in the

forbidden area of each limit, an alarm is generated immediately. (Only

in G22 mode for stored stroke limit 2).

- Releasing the alarms

If the enters a forbidden area and an alarm is generated, the tool can be

moved only in the backward direction. To cancel the alarm, move the

tool backward until it is outside the forbidden area and reset the system.

When the alarm is canceled, the tool can be moved both backward and

forward.

- Change from G23 to G22 in a forbidden area

When G23 is switched to G22 in the forbidden area, the following

results.

(1) When the forbidden area is inside, an alarm is informed in the next

move.

(2) When the forbidden area is outside, an alarm is informed

immediately.

If the tool cannot be moved out of the forbidden area, press the

emergency stop button then release it, set G23 to retract the tool,

correct the setting error, if any, then perform reference position

return again.

CAUTION

When the reference position return function is not

provided for an axis, no forbidden area is set for that

axis, so no forbidden-area alarm is generated for the

axis.

NOTE

1 In setting a forbidden area, if the two points to be set

are the same, the area is as follows:

(1) When the forbidden area is stored stroke check 1,

all areas are forbidden areas.

(2) When the forbidden area is stored stroke check 2

or stored stroke check 3, all areas are movable

areas.

2 Only the three basic axes can be specified in G22.
