Series 15i/150i - MA (Operation) Operators manual Page 578

Operators manual
B-63324EN-1/03 OPERATION 12.INPUTTING/OUTPUTTING DATA
- 557 -
12.5.2 Inputting Tool Offset Data
The following explains the operation for inputting the tool offset data
to the memory of the CNC to a floppy disk.
Setup for input
(1) Select MDI mode.
(2) Follow either of the procedures described below to display the
Tool offset data screen.
Method 1
Press the
OFFSET
SETTING
function key several times, until the Tool
offset data screen appears.
Method 2
(1) Press the
OFFSET
SETTING
function key.
(2) Press the [
TOOL OFFSET
] soft key.
Execution of input
Method 1 (Neither the input file name nor number need be specified)
(1) Press the [READ] soft key.
(2) Press the [TOOL OFFSET] soft key.
Method 2 (The input file is specified with its file name)
(1) Press the [READ] soft key.
(2) Press the ["FILE NAME] soft key.
(3) Enter a file name.
(4) Press the [FILE NAME"] soft key.
(5) Press the [TOOL OFFSET] soft key.
Method 3 (Specified with its file number (one of three methods))
(1) Press the [READ] soft key.
(2) Press the [(FILE#)] soft key.
(3) Enter a file number.
(4) Press the [TOOL OFFSET] soft key.
Method 4 (Specified with its file number (two of three methods))
(1) Press the [READ] soft key.
(2) Press the
N
address key.
(3) Enter a file number.
(4) Press the [TOOL OFFSET] soft key.
Method 5 (Specified with its file number (three of three methods))
(1) Press the
N
address key.
(2) Enter a file number.
(3) Press the [READ] soft key.
