Searching for a file
1) Press the [NO. SEARCH] soft key.
NO. SEARCH is displayed in the key-in buffer.
2) Press the [(FILE#)] soft key.
N is added to the key-in buffer.
3) Enter a file number.
4) Press the [EXEC] soft key.
File search is executed, and the cursor is positioned to the file
having the specified number.
Inputting/outputting data
Inputting data
1) Set input/output data.
See "Setting input/output data," described earlier.
2) On the file list, position the cursor to the desired input file.
See "Displaying a file list," described earlier.
3) Perform the necessary operation, according to the table below:
Input data Input operation
Program
To input all the programs in the file
1) Select EDIT mode.
2) Press the [PROG READ] soft key.
3) Press the [ALL] soft key.
To input a single program as is
1) Select EDIT mode.
2) Press the [PROG READ] soft key.
3) Press the [1_PRGRAM] soft key.
4) Press the [NEW] soft key.
To input a program with its program number changed
1) Select EDIT mode.
2) Press the [PROG READ] soft key.
3) Press the [(PROG#)] soft key.
4) Enter a program number.
5) Press the [EXEC] soft key.
Parameter
1) Select MDI mode.
2) Place the system in an emergency stop state.
3) Press the [DATA READ] soft key.
4) Press the [EXEC] soft key.
Pitch error
Tool compensation
Work offset
Macro variable
Number offset
Fixture offset
Dynamic
compensation
1) Select MDI mode.
2) Press the [DATA READ] soft key.
3) Press the [EXEC] soft key.
Volumetric error
PERIODMAINTE1
PERIODMAINTE2
1) Select EDIT mode.
2) Press the [DATA READ] soft key.
3) Press the [EXEC] soft key.
System log
System configuration
Operation history
The data cannot be input.
