3.MANUAL OPERATION OPERATION B-63324EN-1/03

- 76 -

- T codes (tool functions)

After address T, specify a numeric value of no more than the number of

digits specified by parameter No. 2032.

NOTE

Subprogram calls cannot be performed using T codes.

- B codes (second auxiliary functions)

After address B, specify a numeric value of no more than the number of

digits specified by parameter No. 2033.

NOTE

Subprogram calls cannot be performed using B codes.

- Data input

(1) When addresses and numeric values of a command are types, then

soft key [INPUT] is pressed, the entered data is set. In this case,

the input key is either least input increment or calculator-type

input format according to the setting of bit 0 (DPI) of parameter

No. 2400.

The <INPUT> key on the MDI panel can be used instead of soft

key [INPUT].

(2) Commands for multiple addresses can be types successively.

(3) Key entry is disabled during execution. If soft key [INPUT] or the

<INPUT> key on the MDI panel is pressed during execution, an

"EXECUTION/MODE SWITCHING IN PROGRESS" warning

is generated.

(4) If input data contains an error, the following warnings may be

generated:

Warning Description

FORMAT

ERROR

-G code other than G00, G01, G28 and G30 has been entered.

-An address other than those displayed on the manual numeric

command screen has been entered.

TOO MANY DIGITS

A value that exceeds the following limitations has been entered:

-Address G: 2 digits

-Address P: 1 digit

-Axis address: 9 digits

-M, S, T, B: The parameter-set number of digits

NOTE

Even when the memory protection key is set, key

input can be performed nevertheless.

- Erasing data

(1) When soft key [CLEAR] is pressed, followed by soft key [EXEC],

all set data is cleared. In this case, however, the G codes are set to
