12.INPUTTING/OUTPUTTING DATA OPERATION B-63324EN-1/03

- 558 -

12.6 INPUTTING AND OUTPUTTING WORKPIECE ZERO POINT

OFFSET DATA

12.6.1 Outputting Workpiece zero point offset data

The following explains the operation for outputting the Workpiece zero

point offset data registered in the memory of the CNC to a floppy disk.

Setup for output

(1) Select MDI mode.

(2) Follow either of the procedures described below to display the

Workpiece zero point offset data screen.

Method 1

Press the

OFFSET

SETTING

function key several times, until the

Workpiece zero point offset data screen appears.

Method 2

(1) Press the

OFFSET

SETTING

function key.

(2) Press the [

WORK OFFSET

] soft key.

Execution of output

Method 1 (Neither the output file name nor number need be specified)

(1) Press the [PUNCH] soft key.

(2) Press the [WORK OFFSET] soft key.

Method 2 (The output file is specified with its file name)

(1) Press the [PUNCH] soft key.

(2) Press the ["FILE NAME] soft key.

(3) Enter a file name.

(4) Press the [FILE NAME"] soft key.

(5) Press the [WORK OFFSET] soft key.

Method 3 (Specified with its file number (one of three methods))

(1) Press the [PUNCH] soft key.

(2) Press the [(FILE#)] soft key.

(3) Enter a file number.

(4) Press the [WORK OFFSET] soft key.

Method 4 (Specified with its file number (two of three methods))

(1) Press the [PUNCH] soft key.

(2) Press the

address key.

(3) Enter a file number.

(4) Press the [WORK OFFSET] soft key.
