B-63324EN-1/03 OPERATION 9.SETTING AND DISPLAYING DATA

- 405 -

Operation on the Modem setting screen

Setting the Initial commands

The initial commands which are output to the Modem card at starting

the Remote Diagnosis are set.

At starting the Remote Diagnosis, CNC always outputs the following

basic initial commands to the Modem card.

-ATQ1 :Result code is not returned.

-ATE0 :Command echo is not available.

-AT&D0 :ER status is neglected.

-AT&S0 :DR is always ON.

-AT&K4 :Flow control with XON/XOFF is done.

-ATS0=3 :Number of automatic response is 3.

When more initial commands should be output to the Modem card, the

additional commands can be set.

Procedure for setting

(1) MDI mode is selected.

(2)

The cursor is moved to the command number to be set.

way

1) Move the cursor by the cursor key.

way

1) Press soft key [NUMBER SEARCH].

2) Key –in command number.

3) Press soft key [EXEC].

way

1) Key-in command number

2) Press soft key [NUMBER SEARCH].

(3)

Initial commands are set.

way

1) Key-in initial commands.

2) Press soft key [INPUT], or push the key

INPUT

way

1) Press soft key [INPUT].

2) Key-in initial commands.

3) Press soft key [EXEC].

NOTE

- The maximum number of commands which can be

set is 20.

- The maximum number of characters of an initial

command is 24.
