B-63324EN-1/03 OPERATION 8.EDITING PROGRAMS
- 269 -
(2) Press the [PASTE] soft key.
(3) Press the [(COUNT)#] soft key.
(4) Key in the desired number of times.
(5) Press the [HERE] soft key.
The contents of the copy buffer are inserted ahead of the
cursor the specified number of times.
Method 3
(1) Position the cursor to the position at which the contents of
the copy buffer are to be inserted.
(2) Press the [PASTE] soft key.
(3) Press the address key.
(4) Key in the desired number of times.
(5) Press the [HERE] soft key.
The contents of the copy buffer are inserted ahead of the
cursor the specified number of times.
Pasting a program
Procedure
Method 1
(1) Press the [PASTE] soft key.
(2) Press the [(PROG)#] soft key.
(3) Enter a program number.
(4) Press the [EXEC] soft key.
A program is created with the contents of the copy buffer.
Method 2
(1) Press the [PASTE] soft key.
(2) Press the [(COUNT)#] soft key.
(3) Key in the desired number of times.
(4) Press the [(PROG)] soft key.
(5) Enter a program number.
(6) Press the [EXEC] soft key.
A program is created, with the contents of the copy buffer
being copied the specified number of times.
Method 3
(1) Press the [PASTE] soft key.
(2) Press the address key.
(3) Key in the desired number of times.
(4) Press the [(PROG)#] soft key.
(5) Enter a program number.
(6) Press the [EXEC] soft key.
A program is created, with the contents of the copy buffer
being copied the specified number of times.
