9.SETTING AND DISPLAYING DATA OPERATION B-63324EN-1/03
- 304 -
3 The page keys
PAGE
PAGE
enables paging. Each time paging is
performed, the cursor moves to the top of a page.
- Searching for a workpiece coordinate system
A workpiece coordinate system can be found using a number indicated
in the table below.
No. Found workpiece coordinate system
0 External workpiece origin offset No. 00 (common)
1 to 6 Workpiece coordinate system No. 01 (G54) to No. 06 (G59)
P1 to 48 Additional workpiece coordinate system P01 to P48 (G54.1)
Method 1
(1) Press the [NUMBER SEARCH] soft key.
(2) Key in the number of a workpiece coordinate system to be
found.
(3) Press the [EXEC] soft key.
Method 2
(1) Key in the number of a workpiece coordinate system to be
found.
(2) Press the [NUMBER SEARCH] soft key.
- Entering offsets (absolute input)
Method 1
(1) Press the [INPUT] soft key.
(2) Key in an offset.
(3) Press the [EXEC] soft key.
Method 2
(1) Key in an offset.
(2) Press the [INPUT] soft key.
Method 3
(1) Key in an offset.
(2) Press the
INPUT
key.
- Entering offsets (incremental input)
Method 1
(1) Press the [+INPUT] soft key.
(2) Key in an incremental or decremental value relative to the
current offset.
(3) Press the [EXEC] soft key.
Method 2
(1) Key in an incremental or decremental value relative to the
current offset.
(2) Press the [+INPUT] soft key.
Previous page
Next page
