Series 15i/150i - MA (Operation) Operators manual Page 387

Operators manual
9.SETTING AND DISPLAYING DATA OPERATION B-63324EN-1/03
- 366 -
Method 2
(1) Enter a number you want to set.
(2) Press the [INPUT] soft key.
Method 3
(1) Enter a number you want to set.
(2) Press the
INPUT
key.
NOTE
1 Even if a modification is made to a life value or life
counter value, the tool state and tool change signal
are not affected.
2 After making a life count type change, set a life value
and life counter value again.
- Adding a tool group
Method 1
(1) Select a group for which no data is set.
(2) Position the cursor to the tool data (state, T code, H code, or
D code).
(3) Press the [ADD T CODE] soft key.
(4) Enter a tool number.
(5) Press the [EXEC] soft key.
Method 2
(1) Select a group for which no data is set.
(2) Position the cursor to the tool data (state, T code, H code, or
D code).
(3) Enter a tool number.
(4) Press the [ADD T CODE] soft key.
A service life count type is set according to bit 3 (LTM) of parameter
No. 7400. All of the service life values, service life counter value, H
code, and D codes are set to 0.
- Adding a tool number
Method 1
(1) Position the cursor to the tool data (state, T code, H code, or
D code) immediately preceding the number to be added.
(2) Press the [ADD T CODE] soft key.
(3) Enter a tool number.
(4) Press the [EXEC] soft key.
Method 2
(1) Position the cursor to the tool data (state, T code, H code, or
D code) immediately preceding the number to be added.
(2) Enter a tool number.
(3) Press the [ADD T CODE] soft key.
