B-63324EN-1/03 OPERATION 10.DISPLAY

- 455 -

Storing and canceling the settings of graphic shift/enlarge

The settings of graphic shift/enlarge can be stored in the appropriate

graphic parameters. (The settings of graphic shift/enlarge are not

automatically stored in the graphic parameters, but are cleared when

the power to the CNC is turned off.)

It is possible to cancel the settings of graphic shift/enlarge to redraw the

tool path with the previous settings.

- AFTER SHIFT

Pressing the [AFTER SHIFT] soft key on the tool path drawing screen

or the graphic parameter screen causes the settings of the graphic

shift/enlarge to be stored in the appropriate graphic parameters.

- BEFORE SHIFT

Pressing the [BEFORE SHIFT] soft key on the tool path drawing

screen or the graphic parameter screen causes the settings of the

graphic shift/enlarge to be canceled, making the current settings of the

graphic parameters effective.

NOTE

When the graphic parameter screen is displayed after

graphic shift/enlarge is set up, an @ may appear next

to some settings. The @ indicates that the setting of

the graphic parameter differs from the corresponding

setting made for graphic shift/enlarge. When the

settings of graphic shift/enlarge are stored or canceled,

the @ disappears.
