Series 15i/150i - MA (Operation) Operators manual Page 360

Operators manual

Page of 628

/ 628

B-63324EN-1/03 OPERATION 9.SETTING AND DISPLAYING DATA

- 339 -

9.10 TOOL LENGTH/WORKPIECE ORIGIN MEASUREMENT

The length of a tool can be measured by executing a program command

for automatic tool length measurement (G37) (Section II-16.5,

"Automatic Tool Length Measurement" in Programming) or by

manually moving the tool to the top surface of the workpiece or the like

(Section II-9.8, "Manual Tool Length Measurement"). With tool

length/workpiece origin measurement, tool length measurement can be

simplified, and the setup for machining can be easily made in a short

time. The workpiece origin offset can also be measured easily.

On the tool length offset measurement screen, a T code, M code or

reference position return can be specified by a manual numeric

command.

Procedure for measuring a tool length offset

A tool length offset can be measured by manually bringing the tool into

contact with a workpiece or a reference block.

For details of the actual operation, refer to the manual supplied by the

machine tool builder.

1 Place the machine in the tool replacement position by manual

reference position return or another suitable operation.

2 Press the HANDLE or JOG switch among the mode selection

switches.

3 Turn the tool offset measurement mode switch on the machine

operator’s panel to ON. The screen is automatically replaced by

the tool length offset measurement screen, as shown below. On

the screen, status indication OFST blinks.

The tool length offset measurement screen for offset memories A

and B (geometry compensation is distinguished from wear

compensation) slightly differs from that for memory C (geometry

compensation is distinguished from wear compensation, and

cutter compensation is distinguished from length compensation).

REMOTE MDIMEMORY

EDIT

ZERO

RETURN

JOG

MODE

HANDLE
