B-63324EN-1/03 OPERATION 7.ALARMS AND SELF DIAGNOSTC FUNCTIONS

- 223 -

Input from an NC program

Data can also be input by executing an input/output file as an NC

program.

NOTE

1 No macro statement can be specified in a

G10L60(61) command block.

2 An item name must be specified following

G10L60(61). If an item name is specified in an invalid

position, the item name is assumed to have been

omitted. As a result, that data having the

corresponding item number is deleted.

Input/output on another screen

Data input/output on the periodic maintenance screens can also be

input/output on the floppy disk list screen and memory card screen. For

details, see Section II-10.12, "Floppy Disk List Screen," and Section

II-10.13, "Memory Card Screen."

Alarm

Number Message Contents

SR0125 ILLEGAL EXPRESSION FORMAT

The description of the custom macro statement is

erroneous.

The format of the parameter data is erroneous.
