8.EDITING PROGRAMS OPERATION B-63324EN-1/03

- 284 -

8.17 CONDENSING THE PROGRAM MEMORY

In program memory, NC programs are first registered in contiguous

areas. When an NC program is edited, however, it is divided into

several blocks. The more frequently it is edited, the more it is

fragmented. When an NC program is fragmented, the speed of MEM

operation will slow down and more program memory space is required.

For this reason, it is necessary to condense the program memory to

collect the program into contiguous areas.

Condensing the program memory for the displayed NC program

Procedure

(1) Select EDIT mode.

(2) Follow the procedure described in Section II-10.1, "Programs" to

display the program text screen.

(3) Press the [CONDENSE] soft key.

(4) Press the [THIS] soft key.

Condensing the program memory for a specified single NC program

Procedure

Method 1

(1) Select EDIT mode.

(2) Follow the procedure described in Section II-10.1,

"Programs" to display the program text screen.

(3) Press the [CONDENSE] soft key.

(4) Press the [(PROG#)] soft key.

(5) Enter the number of the program for which the

program memory is to be condensed.

(6) Press the [EXEC] soft key.

Method 2

(1) Select EDIT mode.

(2) Follow the procedure described in Section II-10.1,

"Programs" to display the program text screen.

(3) Press the [CONDENSE] soft key.

(4) Press the address key.

(5) Enter the number of the program for which the program

memory is to be condensed.

(6) Press the [EXEC] soft key.

Method 3

(1) Select EDIT mode.
