10.DISPLAY OPERATION B-63324EN-1/03

- 422 -

(D) Current position

The current positions in the relative, absolute, and machine

coordinate systems can be displayed, as well as the remaining

amount of travel.

To display the current positions in the relative and machine

coordinate systems, press the [RELATIVE] soft key.

To display the current positions in the absolute and machine

coordinate systems, press the [ABSOLUTE] soft key.

To display the current position in the machine coordinate system

and the remaining amount of travel, press the [MACHINE] soft

key.

If the number of controlled axes is seven or greater, use the page

keys to switch the displayed axes.

(E) Modal and other information

The following items of information are displayed:

- Modal G code

The modal G code in the block currently executed is

displayed.

- Remaining number of subprogram calls (L)

The remaining number of subprogram calls is displayed.

- Specified F/actual F

The specified feedrate and the actual feedrate are displayed.

- Specified S/actual S

The specified spindle speed and the actual spindle speed are

displayed.

By setting parameter NOS (bit 0 of No. 2204) to 1, the

display is suppressed.

- Operating time/parts count

Two display items can be selected from among automatic

operation time, cutting time, cycle time, general-purpose

timer time, and machined parts count, with parameters Nos.

2240 and 2241.

- Additional information displayed when an NC window

option exists

The M code (five types) currently being executed, spindle

tool number, next machining tool number, and spindle speed

range are displayed.

Refer to the manual supplied by the machine tool builder for

details.
