B-63324EN-1/03 OPERATION 3.MANUAL OPERATION

- 69 -

Explanation

- When a manual handle feed faster than the rapid traverse rate is specified

When a handle feed faster than the rapid traverse rate is specified, the

command pulses up to the permissible flow amount set in parameter No.

1413 are accumulated in the CNC.

- Distance the tool is moved by manual handle feed

The minimum distance the tool is moved when the manual pulse

generator is rotated by one gradation is equal to the least input

increment. The magnification for the distance the tool is to be moved

can be selected from 10 times and the two magnifications specified by

parameter Nos. 1414 and 1418.

Restrictions

- Number of MPGs

Up to three manual pulse generators can be connected, one for each

axis. The three manual pulse generators can be simultaneously

operated.

WARNING

Rotating the handle quickly with a large magnification

such as x100 moves the tool too fast. The feedrate is

clamped at the rapid traverse feedrate.

NOTE

Rotate the manual pulse generator at a rate of five

rotations per second or lower. If the manual pulse

generator is rotated at a rate higher than five

rotations per second, the tool may not stop

immediately after the handle is no longer rotated or

the distance the tool moves may not match the

graduations on the manual pulse generator.
