Series 15i/150i - MA (Operation) Operators manual Page 570

Operators manual
B-63324EN-1/03 OPERATION 12.INPUTTING/OUTPUTTING DATA
- 549 -
Registering a program with a new program number
- Methods in which neither the input file name nor number need be specified
Method 1
(1) Press the [READ] soft key.
(2) Press the [(PROGRAM#)] soft key.
(3) Enter a program number.
(4) Press the [EXEC] soft key.
Method 2
(1) Press the [READ] soft key.
(2) Press
O
the address key.
(3) Enter a program number.
(4) Press the [EXEC] soft key.
Method 3
(1)
Press
O
the address key.
(2) Enter a program number.
(3) Press the [READ] soft key.
- Methods in which the input file is specified with its file name
Method 1
(1) Press the [READ] soft key.
(2) Press the ["FILE NAME] soft key.
(3) Enter a file name.
(4) Press the [FILE NAME"] soft key.
(5) Press the [(PROGRAM#)] soft key.
(6) Enter a program number.
(7) Press the [EXEC] soft key.
Method 2
(1) Press the [READ] soft key.
(2) Press the ["FILE NAME] soft key.
(3) Enter a file name.
(4) Press the [FILE NAME"] soft key.
(5) Press
O
the address key.
(8) Enter a program number.
(9) Press the [EXEC] soft key.
- Methods in which the input file is specified with its file number
Method 1
(1) Press the [READ] soft key.
(2) Press the [(FILE#)] soft key.
(3) Enter a file number.
(4) Press the [(PROGRAM#)] soft key.
(5) Enter a program number.
(6) Press the [EXEC] soft key.
