8.EDITING PROGRAMS OPERATION B-63324EN-1/03

- 232 -

Stopping registration

While a program is being loaded, pressing the [STOP] soft key causes

loading of the program to stop. Once stopped, loading cannot be

resumed.

Explanation

- Program end codes in files and program numbers

Usually, M02, M30, and M99 are program end M codes. The available

program end codes differ depending on the settings of parameter NPE

(bit 3 of No. 2200) and NM9 (bit 4 of No. 2200), as shown below.

Depending on the available program end codes, the program numbers

differ, as does the way in which programs are separated.

Table 8.1.1 Program End M Codes

Parameter

NPE=0 CNM9=0 NPE=0 CNM9=1 NPE=0 CNM9=0 or 1

Program end M code M02, M30, M99 M02, M30 None

Program number O number or the sequence number

of the start block

O number only

Single program

- Program number to program end

- Program number to program end Program number to

the block immediately preceding the O number

O number to the block immediately

preceding the O number
