B-63324EN-1/03 OPERATION 8.EDITING PROGRAMS

- 273 -

(4) Press the [EXEC] soft key.

The cursor returns to the point to which it was positioned when

the editing operation was performed.

(5) Press the [EXEC] soft key.

Execute UNDO to return the program to its previous state.

NOTE

1 If UNDO is stopped while an NC program is being

restored to its previous state with UNDO, the NC

program returns to the state existing before UNDO

was started. The stored editing operation is,

however, erased.

2 UNDO may fail if restoring a program to its previous

state would leave an extremely small amount of free

space in program memory.

3 UNDO may fail if the program security parameters or

DI signal differs from that when the editing operation

was performed.
