Series 15i/150i - MA (Operation) Operators manual Page 292

Operators manual

Page of 628

/ 628

B-63324EN-1/03 OPERATION 8.EDITING PROGRAMS

- 271 -

8.8.2 Copying, Moving, and Deleting Words and Blocks

Copying a word or block

Procedure

(1) Copy the word or block to be copied.

(2) Select the program to which it is to be copied.

(3) Position the cursor to the desired point.

(4) Paste the word or block.

Moving a word or block

Procedure

(1) Copy the word or block to be moved.

(2) Select the program to which it is to be moved.

(3) Position the cursor to the desired point.

(4) Paste the word or block.

Deleting multiple words or blocks

Procedure

The effects of accidentally deleting and inserting words and blocks can

be canceled. This is called undoing.
