Series 16i/18i/20i/21i/160i/180i/210i/160is/180is/210is - Model A Maintenance manual Page 108

Maintenance manual

Page of 907

/ 907

B--63005EN/02

1. DISPLAY AND OPERATION

(3) Automatic operation status

MTN: Program--specified axis movement is under way.

DWL: Program--specified dwell command (G04) is being executed.

***: Other status

(4) Auxiliary function status

FIN: The completion signal FIN for an auxiliary function is being

awaited.

***: Other status

(5) Emergency stop and reset status (displayed at the location of items

mentioned in (3) and (4))

-- -- E M G -- -- : Emergency stop status

--RESET--: CNC reset status (The state in which the reset signal or

the MDI RESET key remains active.)

(6) Alarm status

ALM : An alarm condition has been detected.

BAT : The lithium battery voltage is low (the battery is to be

replaced).

Blank: Other status

(7) Clock display: Hour:minute:second

(8) Program editing/running status

Input: Data is being input.

Output:Data is being output.

SRCH: A data search is under way.

EDIT: Editing such as insertion or modification is under way.

LSK: Label skip enabled at data input (until valid information is

read).

PTRR: Retract or return/re--positioning is under way when the tool

retrack and return function is used.

HPCC: High--precision contour control mode.

AICC: AI contour control mode.

RVRS: Reversing based on the retrace function.

RTRY: Re--advancing based on the retrace function.

RVED: Reversing based on the retrace function has ended.

Blank: Editing is not under way.
