B--63005EN/02

5. INPUT AND OUTPUT OF DATA

411

(7)The following screen is displayed when you press [SELECT

END]. To start punching, press [EXEC] and to cancel punching,

press [CANCEL].

2. NC OFFSET (HD1) 5. NCOFFSET (HD2) 8. CAP TOOL FILE

3. NC PROGRAM (HD1) 6. NCPROGRAM (HD2) 9. CAP PROGRAM

4. PMC PARAMETER

DATA I/O SCREEN

[ C A P : H E A D --- L ]

EXEC

I/O

SET UP

CANCEL

1. NC P ARAMETER (HD1)

SINGLE

7. NC PARAMETER (HD2)

SINGLE

EXEC REALLY? YES: [EXEC] NO [CANCEL]

PUNCH

When data punching starts, “OUTPUTTING” blinks on the lower

right corner of the screen. The data being output is indicated by

blinks of yellow characters in reverse video. When data outputting

finishes, the data is shown in blue color. If outputting finishes with

an error generated, the data is shown in red.

NOTE

1 The data format output by the above funciton is different

from the data format input/output in an individual operation.

Therefore, output data by this function cannot be used for

inputting.

2 Data format is different between 1--path and 2--path for

two-- path control.

3 The data that can be input by the input/output in a lump

function is limited to data output by the same function.

4 The range of PMC parameters to be output can be specified

by the following NC parameter.

NC parameter

PMCIOS

: The startaddress number of D area of the PMC parameters to be output.

PMCIOE

: The end address number of D area of PMC parameters to be output.

No.9090(PMCIOS)=0, No.9091(PMCIOE)=0

: All the PMC parameters including keep relays, counters,timers and data

are output.

No.9090(PMCIOS)=No.9091(PMCIOE) : 0

: D area data (one data) of the specified address number is output.

No.9090(PMCIOS) < No.9091(PMCIOE)

: D area data of PMC parameters from the specified starting address

number to the ending address number are output.

No.9090(PMCIOS) > No.9091(PMCIOE)

: All the data in D area are output.

9090 PMCIOS

9091 PMCIOE
