A. ALARM LIST
703
Number ContentsMessage
754 SPINDLE--1 ABNORMAL TORQUE
ALM
Abnormal first spindle motor load has been detected.
762 SECOND SPINDLE MODE
CHANGE FAULT
Refer to alarm No. 752.(For 2nd axis)
764 SPINDLE--2 ABNORMAL TORQUE
ALM
Same as alarm No. 754 (for the second spindle)
772 SPINDLE--3 MODE CHANGE ER-
ROR
Same as alarm No. 752 (for the third spindle)
774 SPINDLE--3 ABNORMAL TORQUE
ALM
Same as alarm No. 754 (for the third spindle)
782 SPINDLE--4 MODE CHANGE ER-
ROR
Same as alarm number 752 (for the fourth spindle)
784 SPINDLE--4 ABNORMAL TORQUE
ALM
Same as alarm number 754 (for the fourth spindle)
The details of spindle alarm No. 750 are displayed in the diagnosis display
(No. 409) as shown below.
#7
409
#6 #5 #4 #3
SPE
#2
S2E
#1
S1E
#0
SHE
#3 (SPE) 0 : In the spindle serial control, the serial spindle parameters fulfill the
spindle unit startup conditions.
1 : In the spindle serial control, the serial spindle parameters do not fulfill
the spindle unit startup conditions.
#2 (S2E) 0 : The second spindle is normal during the spindle serial control startup.
1 : The second spindle was detected to have a fault during the spindle
serial control startup.
#1 (S1E) 0 : The first spindle is normal during the spindle serial control startup.
1 : The first spindle was detected to have a fault during the spindle axis
serial control startup.
#0 (SHE) 0 : The serial communications module in the CNC is normal.
1 : The serial communications module in the CNC was detected to have a
fault.
(11)Safety zone alarms
Number Message Contents
4800 ZONE : PUNCHING INHIBITED 1 When a safety zone check was executed, a punch command was
specified in area 1 where punching is inhibited.
4801 ZONE : PUNCHING INHIBITED 2 When a safety zone check was executed, a punch command was
specified in area 2 where punching is inhibited.
4802 ZONE : PUNCHING INHIBITED 3 When a safety zone check was executed, a punch command was
specified in area 3 where punching is inhibited.
4803 ZONE : PUNCHING INHIBITED 4 When a safety zone check was executed, a punch command was
specified in area 4 where punching is inhibited.
4810 ZONE : ENTERING INHIBITED 1 +X When a safety zone check was executed, the machine moving in the
positive X direction entered area 1 into which entry is inhibited.
4811 ZONE : ENTERING INHIBITED 1
-- X
When a safety zone check was executed, the machine moving in the
negative X direction entered area 1 into which entry is inhibited.
D The details of spindle
alarm No.750
Previous page
Next page
