3. STAND--ALONE TYPE i SERIES HARDWARE

B--63005EN/02

324

LEDB Red HSSB communication has been interrupted.

LEDA Red A RAM parity alarm occurred in the common RAM on the

board.

The common RAM is mounted on this board. The RAM

is used to exchange information between the CNC and

personal computer and is not battery--backed.

Status display of the green LEDs j:Off J:On

4321 Status

JJJJ Immediately after power--up

JJJj HSSB board initialization in progress

JJjJ Waiting for the booting of the PC side

JJjj CNC screen displayed on the PC

Jjjj Activation normally terminated, normal operation in progress

jJJj Thermal error detected by the intelligent terminal

jJjJ HSSB communication interrupted

jJjj Parity alarm in the common RAM

jjJJ Communication error

jjJj Battery alarm in the intelligent terminal

Setting Description

0 Setting for maintenance.

The activation menu is displayed, and the PC can perform boot--

up and IPL.

1 Normal setting

The activation menu is not displayed.

The PC cannot perform boot--up or IPL.

2 The NC and PC start up independently of each other .

The activation menu is not displayed.

The PC cannot perform boot--up or IPL.

For details of the boot--up and IPL when the rotary switch is set to 0, see

Appendix, “Maintenance of Open CNC (Boot--Up and IPL).”

D LED display

D High--speed serial bus

setting switch
