9.TROUBLESHOOTING
597
Value TYPE OF I/O DEVICE
0 RS--232--C (control codes DC1 to DC4 are used)
1 FANUC CASSETTE B1/B2 (bubble cassette)
2 FANUC CASSETTE F1 (Old type FLOPPY CASSETTE ADAP-
TOR)
3 FANUC PROGRAM FILE Mate,
FANUC FA CARD ADAPTOR
FANUC FLOPPY CASSETTE ADAPTOR,
FANUC SYSTEM P--MODEL H,
FANUC Handy File
4 Not used
5 Portable tape reader
6 FANUC PPR, FANUC SYSTEM P--MODEL G,
FANUC SYSTEM P--MODEL H
0103 Baud rete
0113
0123
0133
When bit#3 of parameter no. 0135=1 (RS--422 interface), thefollowing
setting is also available.
7
8
600
1200
Value
13
14
15
Baud rate
38400
76800
86400
9 2400
10
11
12
4800
9600
19200
Value Baud rate
Check the following parameters also, when parameter no.0020 is 3.
#7
0134
#6 #5
CLK
#4
NCD
#3 #2
SYN
#1
PRY
#0
#5(CLK) 0 : Internal clock is used for baud rate clock of RS--422 interface.
1 : External clock is used for baud rate clock of RS--422 interface.
#4(NCD) 0 : CD (signal quality detection) of RS--232C interface is checked.
1 : CD (signal quality detection) of RS--232C interface is not checked.
#2(SYN) 0 : In protocol B, NC reset/alarm is not informed to the host.
1 : In protocol B, NC reset/alarm is informed to the host by SYN and
NAK code.
#1(PRY) 0 : No parity bit
1 : With parity bit
0102 Type of I/O device
0112
0122
0132
