Series 16i/18i/20i/21i/160i/180i/210i/160is/180is/210is - Model A Maintenance manual Page 576

Maintenance manual
B--63005EN/02
8. AC SPINDLE (SERIAL INTERFACE)
551
S11:
1st Main
S12:
1st Sub
S21:
2nd Main
S22:
2nd Sub
Proportional gain(HIGH) 4040 4206 4040 4206
Proportional gain (LOW) 4041 4207 4041 4207
Integral gain(HIGH) 4048
4
2
1
2
4048
4
2
1
2
Integral gain(LOW) 4049
4
2
1
2
4049
4
2
1
2
Motor voltage 4083 4236 4083 4236
Regenerative power 4080 4231 4080 4231
S11:
1st Main
S12:
1st Sub
S21:
2nd Main
S22:
2nd Sub
Proportional gain(HIGH) 4042 4208 4042 4208
Proportional gain (LOW) 4043 4209 4043 4209
Integral gain(HIGH) 4050
4
2
1
3
4050
4
2
1
3
Integral gain(LOW) 4051
4
2
1
3
4051
4
2
1
3
Loop gain (HIGH) 4060
4
2
1
8
4060
4
2
1
8
Loop gain (MID, HIGH) 4061
4
2
1
8
4061
4
2
1
8
Loop gain (MID, LOW) 4062
4
2
1
9
4062
4
2
1
9
Loop gain (LOW) 4063
4
2
1
9
4063
4
2
1
9
Motor voltage 4084 4237 4084 4237
Gain change upon completion
of orientation
4064 4220 4064 4220
Stop position shift 4077 4228 4077 4228
PC--type orientation stop posi-
tion
4031 4204 4031 4204
8.1.2.5
Correspondence
between operation mode
and p arameters on
spindle tuning screen
D Normal operation mode
D Orientation mode
Previous page
Next page
