Series 16i/18i/20i/21i/160i/180i/210i/160is/180is/210is - Model A Maintenance manual Page 725

Maintenance manual

Page of 907

/ 907

APPENDIX

B--63005EN/02

A. ALARM LIST

701

204

OFS

MCC

LDA

PMS

#2 #1 #0

#6 (OFS) : A current conversion error has occured in the digital servo.

#5 (MCC) : A magnetic contactor contact in the servo amplifier has welded.

#4 (LDA) : The LED indicates that serial pulse coder C is defective

#3 (PMS) : A feedback pulse error has occured because the feedback cable is

defective.

(7) Over travel alarms

Number Message Contents

500 OVER TRAVEL : +n Exceeded the n --th axis (axis 1--8) + side stored stroke check I.

(Parameter No.1320 or 1326 NOTE)

501 OVER TRAVEL : --n Exceeded the n--th axis (axis 1--8) -- side stored stroke check I.

(Parameter No.1321 or 1327 NOTE)

502 OVER TRAVEL : +n Exceeded the n --th axis (axis 1--8) + side stored stroke check II.

(Parameter No.1322 )

503 OVER TRAVEL : --n Exceeded the n--th axis (axis 1--8) -- side stored stroke check II.

(Parameter No.1323)

504 OVER TRAVEL : +n Exceeded the n --th axis (axis 1--8) + side stored stroke check III.

(Parameter No.1324 )

505 OVER TRAVEL : --n Exceeded the n--th axis (axis 1--8) -- side stored stroke check III.

(Parameter No.1325 )

506 OVER TRAVEL : +n Exceeded the n --th axis (axis 1--8) + side hardware OT.

507 OVER TRAVEL : --n Exceeded the n--th axis (axis 1--8) -- side hardware OT.

508 INTERFERENCE: +n

(T series (two --path control))

A tool moving in the positive direction along the n axis has fouled anoth-

er tool post.

509 INTERFERENCE: --n

(T series (two --path control))

A tool moving in the negative direction along the n axis has fouledanoth-

er tool post.

510 OVER TRAVEL: +n Alarm for stroke check prior to movement. The end point specified in a

block falls within the forbidden area defined with the stroke check in the

positive direction along the N axis. Correct the program.

511 OVER TRAVEL: --n Alarm for stroke check prior to movement. The end point specified in a

block falls within the forbidden area defined with the stroke check in the

negative direction along the N axis. Correct the program.

NOTE

Parameters 1326 and 1327 are effective when EXLM(stroke check switch signal) is on.
