1. Fanuc
  2. Series 16i/18i/20i/21i/160i/180i/210i/160is/180is/210is - Model A

Series 16i/18i/20i/21i/160i/180i/210i/160is/180is/210is - Model A Maintenance manual Page 132

Maintenance manual
B--63005EN/02
1. DISPLAY AND OPERATION
107
Self--diagnosis function
Function
KEY
SW
PWE
=1
Mode
Func-
tion key
Operation
Self--diagno-
sis screen
display
SYSTEM
[DGNOS ]
↓
1. page switch keys
2. Diagnosis data No. → [NO.SRH]
PAGE
PAGE
Boot
Function
KEY
SW
PWE
=1
Mode
Func-
tion key
Operation
System mon-
itor screen
display
Pow-
er--on
time
—
and a soft key at its left
Reading file
from memory
card
Place the cursor at 1. SYSTEM DATA LOADING on the system monitor
screen → [SELECT] → Place the cursor at the target file → [SELECT]
→ [YES]
Listing files in
flash ROM
and display-
ing detail
screen
Place the cursor at 2. SYSTEM DATA CHECK on the system monitor
screen → [SELECT] → Place the cursor at the target item → [SELECT]
Deleting file
from flash
ROM
Place the cursor at 3. SYSTEM DATA DELETE on the system monitor
screen → [SELECT] → Place the cursor at the target file → [SELECT]
→ [YES]
Outputting
file from flash
ROM to
memory c a rd
Place the cursor at 4. SYSTEM DATA SAVE on the system monitor
screen → [SELECT] → Place the cursor at the target file → [SELECT]
→ [YES]
Transferring
contents be-
tween SRAM
and memory
card in batch
Place the cursor at 5. SRAM DATA BACKUP on the system monitor
screen → [SELECT]
-- Batch output to memory card
Place the cursor at 1. SRAM BACK UP → [SELECT] → [YES]
-- Batch input from memory card
Place the cursor at 2. RESTORE SRAM → [SELECT] → [YES]
Deleting file
from memory
card
Place the cursor at 6. MEMORY CARD FILE DELETE on the system
monitor screen → [SELECT] → Place the cursor at the target file →
[SELECT] → [YES]
Memory c a rd
formatting
Place the cursor at 7. MEMORY CARD FORMAT on the system moni-
tor screen → [SELECT] → [YES]
Exiting sys-
tem monitor
Place the cursor at 10. END on the system monitor screen
→ [SELECT] → [YES]
Reference
If no soft key is available as with a touch panel, use the numeric keys on
the MDI keypad.
↓
1
↓
2
↓
3
↓
4
↓
5
↓
6
↓
7
Previous page
Next page
