B--63005EN/02

9.TROUBLESHOOTING

665

A bus error occurred on the local bus on the motherboard (main CPU

board).

This alarm indicates that an error occurred during the exchange of data

within the motherboard (main CPU board).

Replace the CPU card on the motherboard (main CPU board).

Replace the display control card, axis control cards, DRAM module,

FROM module, and SRAM module, one at a time.

Replace the motherboard (main CPU board).

If alarm 972 is issued, indicating on the screen that a local BUS error

occurred on an option board, replace the CPU card on the option card,

DRAM module, axis control cards, and option card, one at a time.

Some option boards have a circuit equivalent to the CPU card installed

on the boards themselves. See the hardware chapter for details.

Screen display example

SYSTEM ALARM

972 NMI O CCURRED IN OTHER MODULE

SLOT 01

976 L-BUS ERROR <SUB

9.37

ALARM 976

(LOCAL BUS ERROR)

Causes and actions

D Replacing the CPU card

D Replacing other cards

and modules

D Replacing the

motherboard (main CPU

board)

D Local BUS error on an

option board
