B--63005EN/02

9.TROUBLESHOOTING

567

It shows that positioning is not yet completed. Check the contents of the

following diagnostic number. (It is 1 in the following condition)

DGN 0300

Position Error

>PARAM 1826

In--position width

1) Check the parameters according to the parameter list.

1825 Servo loop gain per axis (Normal : 3000)

2) Servo system may be abnormal. Refer to servo alarm 400, 410, and

411.

There are a plural interlock signals. Check at first which interlock signal

is used by the machine tool builder at the parameters shown below.

3003

#6 #5 #4

DAU

DIT

ITX

#1 #0

ITL

#0 ITL=0 shows interlock signal *IT is effective. To 1)

#2 ITX=0 shows interlock signal *ITn is effective. To 2)

#3 DIT=0 shows interlock signal MITn is effective. To 3)

#4 DAU=When it is “1,” the interlock signal (MITn) is effective

even in automatic operation.

Go to 3). (Effective in the 20i--T only)

Check state of effective interlock signals using the diagnostic function

(PMCDGN) of the PMC.

1) Interlock signal (*IT) is input.

G0008

#6 #5 #4 #3 #2 #1 #0

*IT

*IT=0 shows that interlock signal is input.

2) Axis interlock signal (*ITn) is input.

*IT8G0130

*IT7

*IT6

*IT5

*IT4

*IT3

*IT2

+IT1

*ITn=0 shows interlock signal is input.

3) Interlock signal per axis and direction (MITn) is input.

D Mseries

G0132

#6 #5 #4 #3

+MIT4

+MIT3

+MIT2

+MIT1

G0134 -- M I T 4 -- M I T 3 -- M I T 2 -- M I T 1

D Tseries

X0004

#6 #5

-- M I T 2

+MIT2

-- M I T 1

+MIT1

#1 #0

MITn=1 shows interlock signal per axis and direction is input.

*InTseries,MITn is effective only when the manual operation is

used.

a. In--position check is

being done

b. Interlock or start lock

signal is input
