9.TROUBLESHOOTING

669

For an explanation of the following SPC alarms (serial pulse coder

alarms), refer to the FANUC CONTROL MOTOR ♠Series Maintenance

Manual (B--65165).

Number Message Contents *

360 n AXIS: ABNORMAL CHECKSUM (INT) A checksum error occurred in the built--in

pulse coder.

350

361 n AXIS: ABNORMAL PHASE DATA (INT) A phase data error occurred in the built--in

pulse coder.

362 n AXIS: ABNORMAL REV. DATA (INT) A rotation speed count error occurred in the

built--in pulse coder.

363 n AXIS: ABNOMAL CLOCK (INT) A clock error occurred in the built--in pulse

coder.

364 n AXIS: SOFT PHASE ALARM (INT) The digital servo software detected invalid

data in the built --in pulse coder.

365 n AXIS: BROKEN LED (INT) An LED error occurred in the built--in pulse

coder.

366 n AXIS: PULSE MISS (INT) An LED error occurred in the built --in pulse

coder.

367 n AXIS: COUNT MISS (INT) A count error occurred in the built--in pulse

coder.

368 n AXIS: SERIAL DATA ERROR (INT) Communication data from the built--in pulse

coder cannot be received.

351

369 n AXIS: DATA TRANS. ERROR (INT) A CRC or stop bit error occurred in the com-

munication data being received from the

built--in pulse coder.

NOTE

The alarm numbers mentioned in the above manual are

those shown in the * column.

9.39

SPC ALARMS
