6. INTERFACE BETWEEN CNC AND PMC

B--63005EN/02

480

Symbol M seriesT seriesAddressSignal name

ALMA F045#0 f f

ALMB

Alarm signal (serial spindle)

F049#0 f f

ALMC F168#0 f f

ALNGH Tool axis direction handle feed mode signal G023#7 — f

AR0toAR15 Actual spindle speed signal F040, F041 f —

ARSTA G071#0 f f

ARSTB

Alarm reset signal (serial spindle)

G075#0 f f

ARSTC G205#0 f f

B00toB31 Second auxiliary function code signal F030 to F033 f f

BAL Battery alarm signal F001#2 f f

BCLP B--axis clamp signal F061#1 — f

BDT1,BDT2toBDT9 Optional block skip signal G044#0, G045 f f

BDTO Software operator’s panel signal (BDT) F075#2 f f

F007#4 f —

econ

aux

ary

unct

on stro

gna

F007#7 — f

BFIN

G005#4 f —

BFIN

econ

aux

ary

unct

on comp

on s

gna

G005#7 — f

BGEACT Background in--use signal F053#4 f f

BGEN Power Mate background in--use signal G092#4 f f

BGIALM Power Mate read/write alarm signal G092#3 f f

BGION Power Mate read/write in--progress signal G092#2 f f

BUCLP B--axis unclamp signal F061#0 — f

CDZ Chamfering signal G053#7 f —

CFINA F046#1 f f

CFINB

Spindle switching completion signal (serial spindle)

F050#1 f f

CFINC F169#1 f f

CHPA F046#0 f f

CHPB

Power line switch signal (serial spindle)

F050#0 f f

CHPC F169#0 f f

CHPCYL Chopping in--operation signal F039#3 — f

CHPMD Chopping in--progress signal F039#2 — f

CHPST Chopping activation signal G051#6 — f
