B--63005EN/02

3. STAND--ALONE TYPE i SERIES HARDWARE

335

Type Item Drawing No. Remarks

16i/160i

Basic unit with 1 slot A02B--0265--B501

Basic unit with 3 slots A02B--0265--B503

18i/180i

Basic unit with 1 slot A02B--0266--B501

Basic unit with 3 slots A02B--0266--B503

21i/210i Basic unit with 1 slot A02B--0267--B501

Type Item Drawing No. ID Remarks

Master PCB Main CPU board

A16B--3200--0320 E8 16i

A16B--3200--0325 E9 18i

A16B--3200--0326 EA 21i

Card PCB CPU card

A20B--3300--0050 01

A20B--3300--0070 09

A20B--3300--0170 11

Display control card

LCD/MDI A20B--3300 --0161 —

For CRT link A20B--3300--0162 —

MDI only A20B --3300--0190 —

Axis control card Servo software

A17B--3300--0200 07 8-- axes

ser

es suppor

90A3 series supported

A17B--3300--0201 06 6-- axes

A20B--3300--0120 05 4-- axes

A20B--3300--0121 04 2-- axes

Servo software

90A7 series supported

A17B--3300--0300 06 6-- axes

Display control card

(

)

10.4 color A20B--3300--0150 0E Graphic

(

)

9.5 monochrome A20B--3300--0153 06 Graphic

9.5 monochrome A20B--3300--0090 07 Character only

3.5

UNITS AND PRINTED

CIRCUIT BOARDS

3.5.1

Basic Units

3.5.2

Printed Circuit Boards

of Control Unit
