1. Fanuc
  2. Series 16i/18i/20i/21i/160i/180i/210i/160is/180is/210is - Model A

Series 16i/18i/20i/21i/160i/180i/210i/160is/180is/210is - Model A Maintenance manual Page 478

Maintenance manual
B--63005EN/02
6.INTERFACE BETWEEN CNC AND PMC
453
Function Contents
Display of sequence program Dynamic display of ladder diagram
Diagnostic function S Title data display
S signal status (symbol can be displayed)
S PMC alarm display
S Signal trace
S Memory contents display
S Signal waveform display
S Task status display (PMC--RC3/RC4 only)
S I/O connection status display
Setting and displaying data S Timer
S Counter
S Keep relay
S Data table
Sequence program edit function Ladder diagram editing
(A ladder edit module is required It is not required
when PMC language board is used.)
(1)R9000 (Operation output register for the ADD, SUB, MULB, DIVB,
and COMPB functional instructions)
#7
Operation result
register
#6 #5 #4 #3 #2 #1 #0
Zero
Sign is minus
Overflow
VNZR9000
(2)R9000 (Error output for the EXIN, WINDR, WINDW, MMCWR,
MMCWW, MMC3R, and MMC3W functional instructions)
#7 #6 #5 #4 #3 #2 #1 #0
The instruc-
tion ended in
error.
R9000
6.2.3
Built--in Debug
Function
6.2.4
System Reserve Area
of Internal Relay
