A. ALARM LIST
691
Number ContentsMessage
5061 ILLEGAL FORMAT IN G02.3/G03.3 The exponential interpolation command (G02.3/G03.3) has a formater-
ror .
Address I, J, or K is not specified.
The value of address I, J, or K is 0.
5062 ILLEGAL COMMAND IN
G02.3/G03.3
The value specified in an exponential interpolation c ommand
(G02.3/03.3) is illegal. A value thatdoes not allow exponentialinterpola-
tion is specified. (For example, a negative value is specified in In.)
5063 IS NOT PRESET AFTER REF.
(M series)
Function category:
Workpiece thickness measurement
Alarm details
The position counter was not preset before the start of workpiece thick-
ness measurement. This alarm is issued in the following cases:
(1) An attempt has been made to start measurementwithout first estab-
lishing the origin.
(2) An attempt has been made to start measurement without first pre-
setting the position counter after manual return to the origin.
5064 DIFFERRENT AXIS UNIT (IS--B,
IS--C)
(M series)
Circular interpolation has been specified on a plane consisting of axes
having different increment systems.
5065 DIFFERENT AXIS UNIT (PMC AXIS)
(M series)
Axes having different increment systems have been specified in the
same DI/DO group for PMC axis control. Modify thesetting ofparameter
No. 8010.
5066 RESTART ILLEGAL SEQUENCE
NUMBER
(M series)
Sequence number 7xxx has been read during search for the next se-
quence number at program restart for the return/restart function.
5067
(HPCC) (M series)
HPCC mode cannot be canceled during G51 (scaling) or G68 (coordi-
nate system rotation).
Correct the program.
5068 G31 P90 FORMAT ERROR
(M series)
The continuous high--speed skip command has one of the following er-
rors:
1. The axis along which the tool is moved is not specified.
2. More than one axis is specified as the axis along which the tool is
moved.
Alternatively, the EGB skip command has one of the following errors:
1. A move command is specified for the EGB axis (workpiece axis).
2. More than one axis is specified.
3. P is not specified.
4. The specified Q value exceeds the allowable range.
Correct the program.
5069 WHL--C:ILLEGA
P-- DATA
(M series)
The P data in selection of the grinding--wheel wear compensation cen-
ter is illegal.
5073 NO DECIMAL POINT No decimal point has been specified for an address requiring a decimal
point.
5074 ADDRESS DUPLICATION ERROR The s ame address has been specified two or more times in a single
block. Alternatively, two or more G codes in the same group have been
specifiedinasingleblock.
5082 DATA SERVER ERROR This alarm is detailed on the data server message screen.
5085 The command format of a smooth interpolation command block has an
error.
