7. DIGITAL SERVO

B--63005EN/02

536

DTEAlarm4

CRC

STB

PRM

#3 #2 #1 #0

DGN (203) :

#7 (DTE) : Communication error of serial pulse coder.

There is no response.

#6 (CRC) : Communication error of serial pulse coder.

Transmitted data is in error.

#5 (STB) : Communication error of serial pulse coder.

Transmitted data is in error.

#4 (PRM) : The alarm is detected by the servo, the values specified in the

parameter is not correct.

Alarm5

OFS

MCC

LDM

PMS

#2 #1 #0

DGN (204) :

#6 (OFS) : A/D conversion of current value of digital servo is abnormal.

#5 (MCC) : Contacts of electro--magnetic contactor of servo amplifier is blown

#4 (LDM) : LED of serial pulse coder is abnormal.

#3 (PMS) : No. of feedback pulses are in error because serial pulse coder C or

feedback cable is faulty.
