6. INTERFACE BETWEEN CNC AND PMC

B--63005EN/02

452

Model

Character Signal description

Series 20i-- M O D E L

A/Series 21i-- M O D E L

PMC--SA1 PMC--SA5

Input signal from the machine to

PMC (MT to PMC)

X0 to X127 (Note)

Output signal from the PMC to ma-

chine(PMCtoMT)

Y0 to Y127 (Note)

F Input signal from the NC to PMC

(NC to PMC)

F0 to F255

F1000 to F1255

F0 to F511

G Output signal from the PMC to NC

(PMC to NC)

G0 to G255

G1000 to G1255

G0 to G255

G1000 to G1255

R Internal relay R0 to R999

R9000 to R9099

R0 to R999

R9000 to R9117

A Message request signal A0 to A24 A0 to A24

C Counter C0 to C79 C0 to C79

K Keep relay K0 to K19 K0 to K19

T V ariable timer T0 to T79 T0 to T79

D Data table D0 to D1859 D0 to D1859

L Label number — L1 to L9999

P Subprogram number — P1 to P512

NOTE

The addresses (X1000 and up, Y1000 and up) for built--in

I/O cards are also reserved. I/O allocation in these areas is

not allowed. Do not use X1000 and up and Y1000 and up.
