5. INPUT AND OUTPUT OF DATA
395
7. Convenient method
1) To change parameters in bit unit, press cursor key
or ,
then the cursor becomes bit length and you can set parameters bit
by bit (Bit parameter only).
2) To set data consecutively, use
EOB
key.
(Ex.1)
1 2 3 4 EOB 4 5 6 7 EOB 9
9 9 9
INPUT
This key sequence sets data as follows:
0 1234
0 4567
0
9999
00
(Ex.2)
1 2 3 4 EOB EOB 9 9 9 9
INPUT
This key sequence sets data as follows:
0 1234
00
0
9999
00
3) To set the same data sequentially, press
= .
(Ex.)
1 2 3 4 EOB a EOB a
INPUT
This key sequence sets data as follows:
0 1234
0 1234
0
1234
00
4) Bit parameters can be set as follows:
(Ex.)
1 1 EOB a EOB a
INPUT
This key sequence sets data as follows:
000
0 0000 00011000
00000000 00011000
00000000 000
1 1000
00000000 00000000
8. After the required parameters are set, set PARAMETER WRITE to
0.
