Series 16i/18i/20i/21i/160i/180i/210i/160is/180is/210is - Model A Maintenance manual Page 504

Maintenance manual

Page of 907

/ 907

B--63005EN/02

6.INTERFACE BETWEEN CNC AND PMC

479

Symbol M seriesT seriesAddressSignal name

*PLSST Polygon spindle stop signal G038#0 f —

*SCPF Spindle clamp completion signal G028#5 f —

*SP Automatic operation hold signal G008#5 f f

*SSTP Spindle stop signal G029#6 f f

*SSTP1 G027#3 f —

*SSTP2

Specified--axis stop signal

G027#4 f —

*SSTP3 G027#5 f —

*SUCPF Spindle unclamp completion signal G028#4 f —

*TLV0to*TLV9 Tool life count override signal

G049#0 to

G050#1

— f

*TSB Tailstock barrier select signal G060#7 f —

+J1to+J8 Feed axis direction select signal G100 f f

+J1O to +J4O Software operator’s panel signal (+J1 to +J4)

F081#0, #2,

#4, #6

f f

+Jg, --Jg, +Ja, --Ja Feed axis direction select s ignal G086#0 to #3 f f

+LM1 to +LM8 Stroke limit external setting signal G110 — f

+MIT1, +MIT2 Manual feed interlock signal in each axis direction X004#2, #4 f —

+MIT1, +MIT2 Tool compensation amount write signal X004#2, #4 f —

+MIT1to+MIT4 Interlock s ignal in each axis direction G132#0 to #3 — f

-- J 1 t o -- J 8 Feed axis direction select signal G102 f f

-- J 1 O t o -- J 4 O Software operator’s panel signal (--J1 to --J4)

F081#1, #3,

#5, #7

f f

-- L M 1 t o -- L M 8 Stroke limit external setting signal G112 — f

-- M I T 1 , -- M I T 2 Manual feed interlock signal in each axis direction X004#3, #5 f —

-- M I T 1 , -- M I T 2 Tool compensation amount write signal X004#3, #5 f —

-- M I T 1 t o -- M I T 4 Interlock signal in each axis direction G134#0 to #3 — f

ABTQSV Servo axis abnormal load detection signal F090#0 f f

ABTSP1 First spindle abnormal load detection signal F090#1 f f

ABTSP2 Second spindle abnormal load detection signal F090#2 f f

ABTSP3 Third spindle abnormal load detection signal F090#3 f f

AFL Auxiliary function lock signal G005#6 f f

AL Alarm in --progress signal F001#0 f f
