A. ALARM LIST
681
Number ContentsMessage
131 TOO MANY EXTERNAL ALARM
MESSAGES
Five or more alarms have generated in external alarm message.
Consult the PMC ladder diagram to find the cause.
132 ALARM NUMBER NOT FOUND No alarm No. concerned exists in external alarm message clear.
Check the PMC ladder diagram.
133 ILLEGAL DATA IN EXT. ALARM MSG Small s ection data is erroneous in external alarm message or external
operator message. Check the PMC ladder diagram.
135
ILLEGAL ANGLE COMMAND
(M series)
The index table indexing positioning angle was instructed in other than
an integral multiple of the value of the minimum angle.
Modify the program.
1
3
5
SPINDLE ORIENTATION PLEASE
(T series)
Without any spindle orientation , an attept was made for spindle index-
ing. Perform spindle orientation.
136
ILLEGAL AXIS COMMAND
(M series)
In index table indexing.Another controlaxis was instructed togetherwith
the B axis.
Modify the program.
1
3
6
C/H--CODE&MOVECMDINSAME
BLK. (T series)
A move command of other axes was specified to the same block as
spindle indexing addresses C, H. Modify the program.
137 M --CODE & MOVE CMD IN SAME
BLK.
A move command of other axes was specified to the same block as M--
code related to spindle indexing. Modify the program.
138 SUPERIMPOSED DATA OVER-
FLOW
The total distribution amount of the CNC and PMC is too large during
superimposed control of the extended functions for PMC axis control.
139 CAN NOT CHANGE PMC CONTROL
AXIS
An axis is selected in commanding by PMC axis control.
Modify the program.
141 CAN NOT COMMAND G51 IN CRC
(M series)
G51 (Scaling ON) is commanded in the tool offset mode.
Modify the program.
142 ILLEGAL SCALE RATE
(M series)
Scaling magnification is commanded in other than 1 -- 999999.
Correct the scaling magnification setting (G51 P
p
......................
or parameter 5411 or 5421).
143 SCALED MOTION DATA OVER-
FLOW
(M series)
The scaling results, move distance, coordinate value and circularradius
exceed the maximum command value. Correct the program or scaling
mangification.
144 ILLEGAL PLANE SELECTED
(M series)
The coordinate rotation plane and arc or cutter compensation C plane
must be the same. Modify the program.
145 ILLEGAL CONDITIONS IN POLAR
COORDINATE INTERPOLATION
The conditions are incorrect when the polar coordinate interpolation
starts or it is canceled.
1) In modes other than G40, G12.1/G13.1 was specified.
2) An error is found in the plane selection. Parameters No. 5460 and
No. 5461 are incorrectly specified.
Modify the value of program or parameter.
146 IMPROPER G CODE G codes which cannot be specified in the polar coordinate interpolation
mode was s pecified. See section II--4.4 and modify the program.
148 ILLEGAL SETTING DATA
(M series)
Automatic corner override deceleration rate is out of the settable range
of judgement angle. Modify the parameters (No.1710 to No.1714)
149 FORMAT ERROR IN G10L3
(M series)
A code other than Q1,Q2,P1 or P2 was specified as the life count type
in the extended tool life management.
150 ILLEGAL TOOL GROUP NUMBER Tool Group No. exceeds the maximum allowable value.
Modify the program.
151 TOOL GROUP NUMBER NOT
FOUND
The tool group commanded in the machining program is not set.
Modify the value of program or parameter.
152 NO SPACE FOR TOOL ENTRY The number of tools within one group exceeds the maximum value re-
gisterable. Modify the number of tools.
