1. Fanuc
  2. Series 16i/18i/20i/21i/160i/180i/210i/160is/180is/210is - Model A

Series 16i/18i/20i/21i/160i/180i/210i/160is/180is/210is - Model A Maintenance manual Page 606

Maintenance manual
B--63005EN/02
9.TROUBLESHOOTING
581
Signal End state
Finish signal 0 1
store signal 0 1
CNC is reading an axis command (X,Y,Z,...) in a program and giving the
command to the axis.
CNC is reading a dwell command (G04) in a program and is executing
the dwell command.
Positioning (G00) to a specified position of a specified axis is not
completed.
Whether positioning is completed or not is checked as the servo position
error amount. Check it CNC’s diagnostic function as follows:
DGN no.300
Position Error
> PARAM 1826
In--position width
Position error amount almost becomes 0, when positioning of an axis
completes and when the amount becomes within the in--posiiton width,
it is assumed that positioning completes and the next block is exected.
If position error amount does not become within the in--position width,
refer to servo alarm 400, 4n0 and 4n1.
Actual feedrate is overridden by the override signals to a programmed
feedrate. Check the override signals using the PMC’s diagnostic function
(PMCDGN).
<Normal override signal>
#7
*FV7G0012
#6
*FV6
#5
*FV5
#4
*FV4
#3
*FV3
#2
*FV2
#1
*FV1
#0
*FV0
*FVn :Feedrate override
<2nd override signal (option)>
Feed rate is overridden more finely using the signals below:
See MTB’s manual whether this feature is equipped.
#7
*AFV7G0013
#6
*AFV6
#5
*AFV5
#4
*AFV4
#3
*AFV3
#2
*AFV2
#1
*AFV1
#0
*AFV0
*AFVn :2nd feed rate override
<State of override signal>
*FV7⋅⋅⋅⋅⋅⋅⋅*FV0
11111111
11111110
:
10011011
:
00000001
00000000
0%
1%
:
100%
:
254%
0%
*AFV7⋅⋅⋅⋅⋅⋅*AFV0
11111111
11111110
:
10011011
:
00000001
00000000
0%
1%
:
100%
:
254%
0%
b.Travel command is being
executed
c. A dwell command is
being executed
d. In--position check
(confirming positioning)
is being done
e. Feedrate override is at
0%
