2. LCD--MOUNTED TYPE i SERIES HARDWARE

B--63005EN/02

284

WARNING

Only those personnel who have received approved safety

and main tenance training may perform this replacement

work.

When opening the cabinet and replacing a unit, be care ful

not to touch the high--voltage circuits (marked and fitted

with an insulating cover).

Touching the uncovered high--voltage circuits presents an

extremely dangerous electric shock hazard.

CAUTION

Before starting replacement work, back up the contents

(such as parameters and programs) of the SRAM memory

of the CNC. Otherwise, the contents of the SRAM memory

may be lost during replacement work.

Backlight

Ordering

information

Individual ordering

information

For 7.2 LCD Made by Hitachi

A61L-0001-0142#BL

For 7.2 LCD Made by Sharp

A61L-0001-0142#BLS

For 8.4 LCD A02B-0236-K113 A61L-0001-0162#BL

For high--intensity 8.4 LCD (for FS20i) A02B-0236-K119 A61L-0001-0176#BL

For 9.5 LCD A02B-0236-K114 A61L-0001-0154#BL

For 10.4 LCD (old type) A02B-0236-K115 A61L-0001-0163#BL

For high--intensity 10.4 LCD A02B-0236-K116 A61L-0001-0168#BL

For 12.1 LCD A02B-0236-K117 A61L-0001-0174#BL

2.12

REPLACING LCD

BACKLIGHT

D Backlight ordering

information
