Series 16i/18i/20i/21i/160i/180i/210i/160is/180is/210is - Model A Maintenance manual Page 164

Maintenance manual

Page of 907

/ 907

B--63005EN/02

1. DISPLAY AND OPERATION

139

NOTE

1 An attempt to set up the count type for a non--registered

item or an item for which the service life has not been set u p

results in the warning message “EDIT REJECTED”.

2 Soft keys [INPUT] and [+INPUT] are ignored.

3 In leap years, an error of 2 4 hours occurs in the all-- time

count.

4 Pressing soft key [CLEAR] results in the warning message

“EDIT REJECTED”.

Pressing soft key [PUNCH] enables registered data to be output to an

external unit.

Pressing soft key [READ] enables data to be input from an external unit.

These operations can be done on the status, setting, and machine system

menu screens.

EDIT *** ***** *** **** 19:27:05

[ ][ READ ][ PUNCH ][ ][ ]

[ ][ ][ ][ CAN ][ EXEC ]

After the EDIT mode is selected, pressing soft key [PUNCH] outputs the

registered data in the following format.

- Format for output from the status and setting screens

G10L60P01AaRr[n]Qq;

G10L60P02AaRr[n]Qq;

G10L60P03AaRr[n]Qq;

- Format for output from the machine system menu

G10L61P01[n] ;

G10L61P02[n] ;

G10L61P03[n] ;

1.19.5

Registered Data

Input/Output

D Data output

Format
