Series 16i/18i/20i/21i/160i/180i/210i/160is/180is/210is - Model A Maintenance manual Page 556

Maintenance manual

Page of 907

/ 907

B--63005EN/02

7. DIGITAL SERVO

531

The amplifier maintenance screen displays the following items:

D AXIS NO. (controlled axis number)

D NAME (controlled axis name)

D AMP (type of amplifier connected to each axis)

D SERIES (servo amplifier series of an amplifier connected to each axis)

D UNIT (unit type of a servo amplifier connected to each axis)

D NO. OF AXES (maximum number of axes controlled by an amplifier

connected to each axis)

D CURRENT (maximum rating for amplifiers connected to each axis)

D VERSION (unit version number of an amplifier connected to each

axis)

D TEST DATE (date of test performed on an amplifier connected to each

axis)

Example) 970123 = January 23, 1997

D MAINTENANCE NO. (engineering change number for an amplifier

connected to each axis)

On an FSSB setting screen (other than the amplifier maintenance screen),

pressing soft key [(OPRT)] displays the following soft keys:

SET INPUTREAD

To enter data, place the machine in MDI mode or theemergency stop state,

position the cursor to the point where a desired item is to be input, then

enter the desired data and press soft key [INPUT] (or the

INPUT

key on the

MDI panel).

When soft key [SET] is pressed after data has been entered, a warning

message is displayed if the entered data contains an error. When the data

is satisfactory, the corresponding parameter is set up.

To restore the previous value of a parameter if, for example, an entered

value is incorrect, press soft key [READ].

When the power is turned on, values are read from the parameters and

displayed on the screen.

CAUTION

1 For the parameters to be specified on the FSSB setting

screen, do not attempt to enter values on the parameter

screen using the MDI or a G10 command. Use only the

FSSB screen to enter values for these parameters.

2 If pressing soft key [SET] results in a warning message

being displayed, retry data entry, or press soft key [READ]

to clear the warning message. Note that pressing the reset

key does not clear the warning message.

D Setting
